CM系列棒狀加熱器式

熱流道系列

CM系列棒狀加熱器式

熱流道系列

一穴偏心、兩穴"一"形、兩穴"T"形、三穴"Y"形、四穴"X"形、四穴"H"型

一穴偏心

SERIES M T S B K ØD ØF ØW X
CMI-080 80 60 40 35 M8 45
6
8
 10 ---
CMI-090 90 70 40 40 M8 45
10
12
 12.7 ---
CMI-100 100 80 50 45 M8 50
16
18
 12.7 ---
加入詢問函

兩穴"一"形

SERIES M T S B K ØD ØF ØW X
CMI-080 80 60 40 35 M8 45
6
8
 10 ---
CMI-090 90 70 40 40 M8 45
10
12
 12.7 ---
CMI-100 100 80 50 45 M8 50
16
18
 12.7 ---
加入詢問函

兩穴"T"形

SERIES M T S B K ØD ØF ØW X
CMI-080 80 60 40 35 M8 45
6
8
 10 ---
CMI-090 90 70 40 40 M8 45
10
12
 12.7 ---
CMI-100 100 80 50 45 M8 50
16
18
 12.7 ---
加入詢問函

三穴"Y"形

SERIES M T S B K ØD ØF ØW X1 X2 Y
CMY-080 80 60 40 35 M8 45
6
8
 10 --- --- ---
CMY-090 90 70 40 40 M8 45
10
12
 12.7 --- --- ---
CMY-100 100 80 50 45 M8 50
16
18
 12.7 --- --- ---
加入詢問函

四穴"X"形

SERIES M T S B K ØD ØF ØW X Y
CMY-080 80 60 40 35 M8 45
6
8
 10 --- ---
CMY-090 90 70 40 40 M8 45
10
12
 12.7 --- ---
CMY-100 100 80 50 45 M8 50
16
18
 12.7 --- ---
加入詢問函

四穴"H"形

SERIES M T S B K ØD ØF ØW U X Y
CMH-080 80 60 40 35 M8 45
6
8
 10 26 --- ---
CMH-090 90 70 40 40 M8 45
10
12
 12.7 31 --- ---
CMH-100 100 80 50 45 M8 50
16
18
 12.7 36 --- ---
加入詢問函
